Revit Drafting Services

Eagle BIM provide accurate and quality Revit drafting services to the AEC professionals like architects, engineers, designers and contractors across USA.

Our drafting experts have gained proficiency in Autodesk Revit by sharpening their skills on multiple projects such as residential, commercial, industrial, hotels, healthcare, and more. We provide our Revit expertise at every step of the project from design to construction to make sure efficiency, productivity and standards are met throughout.

10 +

Years Of Experiences

Types of Revit Drafting

Our Revit Drafting Services

Eagle BIM serves various disciplines when it comes to drafting services. Each project stockholders have specific requirements for drafting their projects. Therefore, we have a comprehensive platform of Revit drafting services which can be used by architectural firms, structural engineers, MEP engineers, subcontractors, general contractor firms and etc.

Architectural Revit Drafting

We provide architectural detailing as per project phase, LOD requirements, standards and then prepare floor plans, elevations, sections, interior and exterior detailing, construction documents set.

Structural Drafting

We create accurate structural detailing of foundations, beams, columns, slabs, erection drawings, rebar & reinforcement drawings and steel drafting for engineers, fabricators, manufacturers.

MEP Revit Drafting

We provide accurate drafting on MEP systems including mechanical/HVAC, electrical, plumbing and fire protection equipment and make sure all are coordinating well together and with architectural & structural.

Revit Shop Drawings

We produce shop drawings directly from Revit models for steel and metal fabrication, cabinetry, casework, millwork, HVAC, plumbing, electrical, fire protection, precast etc.

Revit As-built Drawings

We capture accurate as-built conditions in model and produce as-built documents for architectural floor plans and layouts, MEP and structural drawings and facility management drawings.

Services We Do

Process of our Revit Drafting

We believe quality drafting is not just about putting details in model and drawings but its also about project clarity, how it coordinates with other trades, and of course accuracy in detailing. Therefore, we follow a process which is reliable and useful for drafting services.

Understanding Your Requirements

We kickoff with learning about project drawings, scope of work, expectations of clients, standards and templates that we need to follow, deadlines and goals of the project.

Drafting & Modeling

We set up project in Revit as per standards and started creating drawings and detailing as per the scope of work, while maintaining communication throughout the project for any questions or concerns.

Internal Quality Check

We follow multiple quality checks internally to make sure our deliveries are as per the scope of work, client’s inputs, and project requirements and standards. We keep in mind the turnaround time and quality standards and send them ahead for client review.

Client Review

We quickly address any questions, concerns, changes, adjustments, or revisions required during reviewing and delivering the final output on or before the deadlines.

Have Questions?

Frequently Asked Questions About Scan to BIM Services

What is Revit Drafting?

Revit drafting is a process of using Autodesk Revit to create detailed 2D drawings and 3D models for architectural, structural, MEP systems. It includes details of elements or equipment like annotations, dimensions, symbols, and instructions for construction.

What is the cost of Revit drafting services?

The fixed cost of Revit drafting depends on the multiple factors of the project including complexity, project size, scope of work, level of details (LOD) required, timeline & need of resources. Therefor best way to get an exact estimate is to share your project details with BIM services provider like Eagle BIM who can prepare a detailed quote for you as per your needs.

Is Revit better than AutoCAD?

Revit and AutoCAD are both heavily used software across the AEC industry. The purpose of AutoCAD is primarily on 2D drafting which is great to produce detail line drawings and 2D drawings. On the other hand, Revit is more advanced tool serving BIM platform which combines 2D drafting and 3D modeling. Revit facilitates efficiency and automation in the project which means any change made in Revit updates across all views which saves time and reduces errors. AutoCAD does not have such capabilities therefore Revit is widely used for 2D drafting, 3D modeling, coordination, and team collaboration.
