Why This BIM Coordination Sprint Works (and Why Weeklies Don’t)
Most “weekly coordination” calls drift: updates, screenshares, and not enough decisions. A BIM coordination sprint flips that. In 90 minutes you (1) triage what truly matters, (2) make decisions on the highest-impact coordination issues, and (3) close the loop the same day. Run this weekly and your RFIs drop, your clash detection list shrinks, and your first-pass approvals climb.
This BIM coordination playbook is tool-agnostic. We typically run it with Navisworks for clash tests, BCF topics for issue tracking, and production inside Revit. If you want help wiring this rhythm into a live job in Texas or elsewhere in the USA, our BIM coordination practice uses the same cadence on real scopes.
The BIM Coordination Sprint at a Glance (90 Minutes Total)
Prep – 15 minutes
Curate—not create—work. Refresh the clash set, group duplicates, rank by impact, and publish a short agenda.
Gatekeeper – 45–60 minutes
Decide only on parent issues that affect dates, cost, safety, or code. Everything logs as BCF topics (no screenshots).
Close-out – 15–30 minutes
Apply decisions to the model, regenerate the set, send a five-line summary, and update exactly one rule in your BEP.
That’s it. Small, boring, and repeatable—the kind of BIM coordination that actually moves a project.
Roles That Keep BIM Coordination Tight
Coordinator (owner of BIM coordination):
Runs the clash test, groups issues, sets the agenda, and moderates the call.
Discipline leads (Arch / Str / MEP):
Arrive with A/B options and a recommendation.
Gatekeeper (PM / CM / GC):
Breaks ties, enforces timeboxes, and records final decisions.
Scribe:
Logs BCF topics with clear titles, owners, and next steps.
On complex scopes, we often embed this BIM coordination sprint inside an MEP BIM workstream so the same people who will update the model and sheets are present.
PREP (15 Minutes): BIM Coordination Without the Noise
1) Refresh and Freeze
-
Regenerate the Navisworks clash test from the latest model set.
-
Freeze versions for the sprint window (no silent updates).
2) Group Duplicates
-
Collapse repeat hits into one parent issue (example: “Duct elevation offset along grid C, Levels 3–5”).
-
Kill anything outside this week’s BIM coordination scope.
3) Score Impact
-
Score each parent issue 1–5 based on critical path, safety, and cost.
-
Rank the top 10–15 parents—this becomes your agenda.
4) Publish the Mini-Agenda
Send 30 minutes before the call:
“We’ll cover 12 parent BIM coordination issues; goals are approve, redesign, or park. BCF link inside.”
GATEKEEPER: Making BIM Coordination Decisions That Stick
Ground rules (read at the start):
-
Decide on parents, not every child clash.
-
Options must be A/B with a recommendation.
-
If no decision in five minutes, park it and assign a duo.
What this sounds like:
“This BIM coordination issue blocks the curtainwall crew by Thursday. Option A: raise duct 75 mm. Option B: shift hanger line. Recommendation: A.”
How to log decisions fast:
-
Title: PLANT-3 / Duct vs Beam / Elevation Offset / APPROVED A
-
Note: Raise main 75 mm; confirm firestopping detail.
-
Attach: Viewpoint, owner, due date.
We keep the issue trail clean so downstream shop drawings don’t inherit confusion.
CLOSE-OUT: Lock BIM Coordination Decisions the Same Day
1) Apply Decisions
Owners make changes immediately or stage the work.
Coordinator re-runs clash detection to verify approved issues are resolved.
2) Send a Five-Line Summary
-
12 parents reviewed; 9 approved; 2 parked; 1 redesign
-
Two code checks pending
-
Next sprint focus and required attendees
-
Link to BCF board and snapshot
3) Update One BEP Rule
Example: “All main duct centerlines on Level 3 target elevation X ±25 mm unless logged as an exception.”
One rule per coordination sprint prevents BEP bloat.
What BIM Coordination Looks Like in a Plant Room (Composite Example)
First run: 156 raw clashes in a dense riser bank.
After grouping: 18 parent BIM issues.
Gatekeeper discussed: 10.
Closed in a week: 9.
The result showed up cleanly in Revit drafting, and the next clash detection pass dropped by 80%. No email chains—everything lived as BCF topics with viewpoints.
Assets That Make BIM Coordination Sprints Work
Decision-ready viewpoints:
One image per parent issue with arrows and intent.
A/B option worksheet:
A: fastest path.
B: cleaner long-term path.
Record who can approve.
A real parking lot:
Start each sprint by clearing 1–2 parked BIM coordination items.
If you want help building these once and reusing them across projects, our drafting team folds them into BIM coordination and Revit drafting deliverables.
Metrics That Prove BIM Coordination Is Working
Track weekly:
-
Parent issues vs raw clashes
-
Approved vs parked ratio
-
Hours to prep the coordination set
-
First-pass approvals on affected sheets
-
Email threads replaced by BCF topics
When these move, you’re saving real time—and real money.
Common Coordination Pitfalls (and Fixes)
-
Over-modeling before decisions: Keep LOD tight to this week’s goal.
-
No owner on parked items: Assign a pair and a due date.
-
Screenshots in email: Move context into BCF.
-
Too many updates: Status belongs in email; BIM coordination sprints are for decisions.
For retrofit work starting from existing conditions, pair this sprint with a slim scan-to-BIM workflow so coordination starts from reality.
Bottom Line
You don’t need a bigger meeting. You need a tighter BIM coordination process that protects attention and creates a visible trail of decisions. Run this 90-minute sprint for two weeks and watch what changes: fewer loops, faster handoffs, cleaner packages.
